AuroraSolar Inverters
YF-TP-HV3P-50K
HV Three-Phase Hybrid Inverter
50 kW hv three-phase hybrid inverter for 135-850 V (250 V rated) battery systems, with 150-850 V solar input.
Ask for pricePrices depend on quantity and project. We reply with a quotation.
- Rated power
- 50 kW
- Battery voltage
- 135-850 V (250 V rated)
- Max. PV input
- 100 kW
- Max. efficiency
- 98.5%
Overview
HV Three-Phase Hybrid Inverter
50 kW hv three-phase hybrid inverter for 135-850 V (250 V rated) battery systems, with 150-850 V solar input.
Available for retail, wholesale and bulk orders, and to dealers. Ask us for a price list or a quotation for your project.
Specifications
| Brand | Aurora |
|---|---|
| Model | YF-TP-HV3P-50K |
| Rated power | 50 kW |
| Battery voltage | 135-850 V (250 V rated) |
| Max. PV input | 100 kW |
| MPPT range | 150-850 V |
| Output | Three-phase, 380/400 VAC |
| MPPT trackers | 4 |
| Max. PV input voltage | 1,000 V |
| Max. charge/discharge current | 2 x 100 A (dual battery inputs) |
| Battery types | Lithium-ion or lead-acid |
| Parallel | Up to 6 units |
| Protection | IP66 |
| Max. efficiency | 98.5% |
| Display | App + LED / LCD |
| Communication | RS485/Wi-Fi/CAN/DRM |
| Dimensions | 544 x 880 x 278 mm |
| Weight | 88 kg |
