AuroraSolar Inverters
YF-LV-P3E-24048
LV Three-Phase Hybrid Inverter
24 kW lv three-phase hybrid inverter for 40-60 VDC battery systems, with 150-950 VDC solar input.
Ask for pricePrices depend on quantity and project. We reply with a quotation.
- Rated power
- 24 kW
- Battery voltage
- 40-60 VDC
- Max. PV input
- 48 kW
- Euro efficiency
- 97.2%
Overview
LV Three-Phase Hybrid Inverter
24 kW lv three-phase hybrid inverter for 40-60 VDC battery systems, with 150-950 VDC solar input.
Available for retail, wholesale and bulk orders, and to dealers. Ask us for a price list or a quotation for your project.
Specifications
| Brand | Aurora |
|---|---|
| Model | YF-LV-P3E-24048 |
| Rated power | 24 kW |
| Battery voltage | 40-60 VDC |
| Max. PV input | 48 kW |
| MPPT range | 150-950 VDC |
| Output | Three-phase, 380/400 VAC |
| MPPT trackers | 2 |
| Max. PV input voltage | 1,000 VDC |
| Max. charge/discharge current | 415 A |
| Battery types | Lithium or lead-acid |
| Parallel | Yes |
| Protection | IP66 |
| Euro efficiency | 97.2% |
| Display | LCD + app |
| Dimensions | 448 x 660 x 265 mm |
| Weight | 48 kg |
